Grosvenor Elegance High Efficiency Gas Fire
- 4.1kW Direct Output
- Glass Fronted - High Efficiency
- 3 Year Guarantee
- 90% Efficiency
Grosvenor High Efficiency (HE) Glass Fronted Inset Gas Fire
- Multi-flue design - requires a min. fireplace depth of 125mm (+ 20mm debris collection)
- Powerful 4.1kW heat output (Gross)
- Glass fronted - High Efficiency
- OVERVIEW: Top of the range slimline high efficiency glass fronted inset gas fire
The Grosvenor is an exceptional high efficiency glass fronted inset gas fire designed to fit multiple flue installations. It is compatible with most pre-cast flues, pre-fabricated flue systems (class 1 or class 2 with min. 127mm / 5" diameter or greater) and conventional class 1 brick built chimneys. The multi-flue firebox fits a standard fireplace opening, typically 16" wide x 22" high (please refer to specification - excludes low lintels) and requires a minimum fireplace depth of only 125mm, plus 20mm for debris collection.
The Grosvenor reinvents the traditional flued inset coal-effect gas fire. The discrete glass front helps increase efficiency by reducing the amount of heat input required while the patented safety draft diverter system increases safety in the event of a flue draft reversal.
The Grosvenor can be specified in Manual Control (Rotary) or Manual (Fingerslide) and is available with coal fuel bed only.The Elegance fret is a traditional vertical cast design with a modern twist that imitates a classic solid fuel fire grate. It has a curved profile and is intended to stand in front of the fire and frame. The ashpan is a separate component and provides access to the controls (depending on the model). The Elegance fret is available in: brass (solid brass), brass & black (solid brass), chrome & black (lightweight aluminium), black (lightweight aluminium). The one-piece frame is held in position with magnets (supplied) and depending on the model is available in: brass effect, chrome effect or black.
Please note the price is dependent upon the final configuration. Natural gas only.
This information is intended for guidance only. Superior Fires recommends booking a Home Survey to determine the actual chimney or flue specification.
Model Identifier | High Efficiency (Glass Fronted) Inset Fuel Effect Gas Fire Gas Category/Pressure = I2H(20) |
---|---|
Heat Input Gross (High) | 5.0kW |
Heat Input Gross (Low) | 3.5kW |
Heat Output Gross (High) | 4.1kW |
Heat Output Gross (Low) | 2.8kW |
Energy Efficiency Class | C |
Direct Heat Output | 4.1kW |
Heat Type | Radiant & Convected Heat |
Chimney Flue Compatibility | Pre-Cast (Minimum Size 12,500mm²), Pre-Fabricated - Class 2 (127mm/5" Diameter), Conventional Chimney - Class 1 (178mm/7" Diameter or Greater) |
Control Ignition | Battery-Free Piezo Spark Ignition (Manual - Rotary Control), Battery Spark Ignition (Manual - Fingerslide Control) |
Control Location | Low Level - Front - Behind Ash Pan (Manual - Rotary Control), High Level - Right - Side (Manual - Fingerslide Control) |
Air Vent Required | Not Required |
Manufacturer Guarantee | 3 Years |
Safety Features | Flame & Oxygen Monitoring Device |
Installation Requirement | Gas Safe Registered Installer (Bord Gais - ROI) |
Installation Information | As with any open fire, a fire guard complying with BS 8423 must be used. Fire guards are intended to protect people from falling into a fire, prevent burns and reduce the risk of injury, particularly to young children and the infirm. In addition it is intended to reduce the risk of fire resulting from clothing and/or other flammable materials coming into contact with, or in proximity to, burning fuel and/or hot surfaces. |
Fuel Type | Natural Gas |
Fire Type | Glass Fronted - High Efficiency |
Installation Type | Inset |
Engine Type | High Efficiency (HE) |
Width Outline A | 480mm |
Height Outline B | 595mm |
Depth Outline C | 125mm |
Rear Width Min D1 | 280mm |
Rear Width Max D2 | 395mm |
Rear Height E | 550mm |
Opening Width Min X1 | 390mm |
Opening Width Max X2 | 450mm |
Opening Height Min Y1 | 550mm |
Opening Height Max Y2 | 575mm |
Opening Depth Min Z | 145mm |
Packaging Width | 575mm |
Packaging Height | 670mm |
Packaging Depth | 360mm |
Packaging Weight | 18.5kg |
Rebate Depth | 125mm |
